Semi automatic 2 shaft aluminium foil rewinding machine is an user friendly model for rewinding the jumbo roll of aluminium foil into small diameter foil roll.
This model adopts surface rewinding method,it can rewind the roll form 2meters up to 300meters etc for house foil roll,kitchen foil roll,cooking foil roll,BBQ foil roll,supermarket foil roll and catering foil roll etc.
Machine is with automatic meter counting,automatic shutdown,automatic deceleration,automatic brake system.
It with with LCD touch color screen,PLC and inverter to secure the heavy duty production.
Technical Data:
Name:Semi Automatic 2 Shaft Aluminium Foil Rewinding Machine
Model:PPD-SAAF450
Unwind roll width:max450mm
Unwind roll ID:3inch
Unwind roll OD:max 600mm
Unwind roll weight:max200kg
Finished roll width:max450mm
Finished roll ID:35/38/40mm or as customized
Finished roll length setting:2-300meters option
Speed:Max150m/min
Total power:2.2kw
Voltage:220/380/415V,50Hz
