Four Side Ice Patch Packaging Machine
2 Lanes ice patch packaging machine is a versatile packaging machine that is designed to handle a variety of products such as ice patches, water gels, cold gels, masks, warm patches, eye patches, foot patches etc.
The machine is equipped with a powerful servo motor, a PLC controller, and flexible bag strength setting and cutting features that help save film time and increase production efficiency.
With a user-friendly touch screen interface, the machine is easy to operate, and parameter settings can be quickly and easily adjusted to meet the needs of different packaging requirements.Features:
1.High sensitivity optical electric color mark tracking &digital input cut position which makes the sealing&cutting more accurate.
2.Separate PID control to temperature, suitable for various packing materials.
3. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
4. Simple driving system, reliable working, convenient maintenance.
Main Data:
Name:2 Lanes Ice Patch Packaging Machine
Model:PPD-IPPM80
Packing material size:OD≤350mm，width≤532mm
Bag size:140x70mm(LxW)
Processing ability:40-80pcs/min
Total power:motor:2.2Kw,heated:3.3Kw
Voltage:220V,50Hz
